Mono
136 ipm
Built-in print controller
Built-in print controller for ultra-fast job processing, large 15” colour touch-screen display for ease of use
Finishing
Powerful inline finishing options
Key features
Monthly page volume
500,000
Paper capacity
18,000 sheets
Improved image stability
Real-time image density and toner ratio sensors maintain image stability over long press runs
Mono
136 ipm
Built-in print controller
Built-in print controller for ultra-fast job processing, large 15” colour touch-screen display for ease of use
Finishing
Powerful inline finishing options
Monthly page volume
500,000
Paper capacity
18,000 sheets
Improved image stability
Real-time image density and toner ratio sensors maintain image stability over long press runs
Specifications
| Device type | Production Printer |
|---|---|
| Category | Monochrome Range |
| Colour or Mono | Mono |
| Print speed | 126-150 PPM |
| Mono output speed (A4 pages per min) | 136 |
| Colour output speed (A4 pages per min) | n/a |
| Print resolution (dpi) | 1200 x 1200 |
| First time to print mono (secs) | 2.7 |
| First time to print colour (secs) | n/a |
| Warm up time (secs) | 420 |
| Output size | A5 – SRA3 |
| Output Size (max) | SRA3 |
| Sheet size PPG only | < or = SRA3 |
| Monthly print volume | 3240000 |
| Average monthly volume (A4 pages per month) | 480000 |
| Average monthly print volume | 480K |
| Duty cycle | 1200000 |
| Standard paper input tray 1 (sheets) | 1500 |
| Standard paper input tray 2 (sheets) | 1500 |
| Standard Paper Input High Capacity Feeder (A4) | 5000 |
| Maximum paper input (sheets) | 18000 |
| Paper weight trays (gsm) | 40 – 300 gsm, up to 350 gsm with PF-710/709 (middle tray) |
| Standard memory (GB) | 16Gb |
| Storage Capacity (Standard) | 1TB x 2 |
| Weight (kg) | Approx. 375 |
| Power requirements (V / Amp / Hz) | 240 / 20 |
| Max power consumption (kW) | 4.8 |
| Automatic duplex unit paper weight (gsm) | 300 gsm |
| Automatic duplex unit max sheet size | SRA3 |
| Options available PPG only | Production Options |
| Stapling unit output | 4200 |
| Folding & punching unit output | FD-503 (1000) |
| Multi GBC punching unit output | GBC G3 |
| Stacking unit output | LS-507 (6000 sheets) |
| Booklet making unit output | 50 |
| Perfect binding output | PB-503 (300 sheets) |
| Operating system support | Windows Vista / Vista 64bit / 2000 / XP / Server 2003, MAC OS 10.2 / 10.4 / 10.5 |
