| Device type |
Multifunction Printer |
| Category |
Multifunction Printer |
| Colour or mono |
Colour |
| Mono output speed (A4 pages per min) |
30 |
| Colour output speed (A4 pages per min) |
30 |
| Print resolution (dpi) |
1200 x 1200 (and 1800 x 600 equivalent enhanced) |
| Copy resolution (dpi) |
600 x 600 |
| First time to print mono (secs) |
5 |
| First time to print colour (secs) |
6.7 |
| Warm up time (secs) |
13 |
| Output size |
SRA3 to A5, B6 Lengthwise, A6 Lengthwise Thick Paper, Foolscap* (200 × 330mm), 8K, 16K, Long Length Paper (210 × 457.3mm to 297 × 1200mm),* Set by Customer engineer |
| Output size max |
SRA3 |
| Standard paper input tray 1 (sheets) |
500 (up to A3) |
| Standard paper input tray 2 (sheets) |
500 (up to SRA3) |
| Standard Paper Input Bypass Tray (sheets) |
150 (up to SRA3) |
| Standard Paper Input High Capacity Feeder (A4) |
3000 |
| Maximum paper input (sheets) |
6650 |
| Paper weight trays (gsm) |
(Tray 1/2) 52 - 256 |
| Paper Weight Bypass Tray (gsm) |
52 - 300 |
| Standard memory (GB) |
8GB |
| Storage Capacity (Standard) |
256 SSD |
| Document feeder (sheets) |
100 |
| Weight (kg) |
(With DF-714) 96 |
| Dimension W x D x H (mm) |
(With DF-714) 615 x 688 x 918 |
| Dimension inclusions |
Dimensions include Automatic Document Feeder (ADF) |
| Power requirements (V / Amp / Hz) |
220-240V / 9A / 50-60Hz |
| Max power consumption (kW) |
1.58 |
| Automatic duplex unit paper weight (gsm) |
52 to 256 gsm |
| Automatic duplex unit max sheet size |
SRA3 |
| Scan type |
Full colour scanner |
| Scanning speed simplex max |
80 |
| Scanning speed duplex max |
37 (DF-632), 200 (DF-714) |
| Interface |
Ethernet (10BASE-T / 100BASE-T / 1000BASE-T) |
| Protocol |
TCP/IP (FTP, SMB, SMTP) |
| Scan resolution |
600 x 600 |
| Output format |
TIFF, PDF, Compact PDF, JPEG, XPS, Compact XPS, PPTx,TIFF, PDF, Compact PDF, JPEG, XPS, Compact XPS, PPTx. Optional: Searchable PDF; PDF/A 1a and 1b; Searchable DOCX/PPTX/XLSX |
| Main functions |
Scan to E-Mail, Scan to FTP, Scan to BOX (SSD), Scan to PC (SMB), Network TWAIN, Scan to WebDAV, Scan to Me, Scan to Home, Scan to USB, Scan to Scan Server, Scan to Web Service (WSD-Scan), Device Profile for Web Services (DPWS) |
| Operating system support |
Windows 7 (32/64), Windows 8./8.1 (32/64), Windows 10 (32/64), Windows Server 2008 (32/64), Windows Server 2008 R2, Windows Server 2012/R2, Windows Server 2016, Windows Server 2019, Mac OS X 10.10, Unix, Linux, Citrix, SAP |
| Processor |
SOC Cortex A72 CPU Quad Core 1.6GHz |
| Supported protocols |
TCP / IP (IPv4, IPv6) IPP, SMB, LPAD, IPP, SNMP (v3), HTTP/HTTPS, SSL/TSL for HTTPS, Port 9100 (bi-directional), Ethernet, AppleTalk |
| Memory |
(Shared with copier) |
| Printer language |
PostScript 3 Emulation (3016), PCL5e/c Emulation, PCL6 (Ver. 3.0) Emulation, XPS Ver. 1.0 |
| Printer interface |
Ethernet (10BASE-T / 100BASE-T / 1000BASE-T), USB 2.0, USB Host |
