| Device type |
Multifunction Printer |
| Colour or mono |
Colour |
| Print speed |
21-30 PPM |
| Mono output speed (A4 pages per min) |
30 |
| Colour output speed (A4 pages per min) |
30 |
| Print resolution (dpi) |
1200 x 1200 (and 1800 x 600 equivalent enhanced) |
| Copy resolution (dpi) |
600 x 600 |
| First time to print mono (secs) |
5.6 |
| First time to print colour (secs) |
7.3 |
| Warm up time (secs) |
20 |
| Output size |
SRA3 to A5, B6 Lengthwise, A6 Lengthwise Thick Paper, Foolscap* (200 × 330mm), 8K, 16K, Long Length Paper (210 × 457.3mm to 297 × 1200mm),* Set by Customer engineer |
| Output size max |
SRA3 |
| Standard paper input tray 1 (sheets) |
500 (up to A3) |
| Standard paper input tray 2 (sheets) |
500 (up to SRA3) |
| Standard Paper Input Bypass Tray (sheets) |
150 (up to SRA3) |
| Standard Paper Input High Capacity Feeder (A4) |
3000 |
| Maximum paper input (sheets) |
6650 |
| Paper weight trays (gsm) |
(Tray 1/2) 52 - 256 |
| Paper Weight Bypass Tray (gsm) |
52 - 300 |
| Standard memory (GB) |
4GB with extra UK-211 |
| Storage Capacity (Standard) |
250 |
| Document feeder (sheets) |
100 |
| Weight (kg) |
(Copier Only) 85 |
| Dimension W x D x H (mm) |
(Copier Only) 615 x 685 x 779 mm |
| Dimension inclusions |
Dimensions don't include Automatic Document Feeder (ADF) |
| Power requirements (V / Amp / Hz) |
220-240V / 9A / 50-60Hz |
| Max power consumption (kW) |
1.84 |
| Automatic duplex unit paper weight (gsm) |
52 to 256 gsm |
| Automatic duplex unit max sheet size |
SRA3 |
| Scan type |
Full colour scanner |
| Scanning speed simplex max |
80 |
| Scanning speed duplex max |
37 (DF-624), 160 (DF-701) |
| Interface |
Ethernet (10BASE-T / 100BASE-TX / 1000BASE-T) |
| Protocol |
TCP/IP (FTP, SMB, SMTP) |
| Dual scan |
Yes |
| Scan resolution |
Push: 200 dpi / 300 dpi / 400 dpi / 600 dpiPull: 100 dpi / 200 dpi / 300 dpi / 400 dpi / 600 dpi |
| Output format |
TIFF, JPEG, PDF, Compact PDF, XPS, Compact XPS, PPTx, DOCx*, XLSx*, Searchable PDF*, PDF / A*, Linearised PDF *optional |
| Main functions |
Scan to E-Mail, Scan to FTP, Scan to BOX (HDD), Scan to PC (SMB), Network TWAIN, Scan to WebDAV, Scan to Me, Scan to Home, Scan to USB, Scan to Scan Server, Scan to Web Service (WSD-Scan), Device Profile for Web Services (DPWS) |
| Operating system support |
Windows 2000 / XP / XP 64bit / Vista / Vista 64bit / 7 / 7 64bit / 8 / 8 64bit / Server 2003 / Server 2003 64bit / Server 2003 R2 / Server 2003 R2 64bit /Server 2008 / Server 2008 64bit / Server 2012 / Mac OS 9.2 / Mac OS X 10.2 / 10.3/10.4 (Power PC) / Mac OS X 10.5 Power PC/Intel / Mac OS X 10.6 /10.7 / 10.8 Intel Linux |
| Processor |
SOC 800 MHz (DualCore) |
| Supported protocols |
TCP / IP, IPX/SPX (NDS support), SMB (NetBEUI), LPD, IPP1.1, SNMP, HTTP |
| Memory |
(Shared with copier) |
| Printer language |
PostScript 3 Emulation (3016), PCL5e/c, PCL6 (Ver. 3.0), XPS Ver. 1.0 |
| Printer interface |
Ethernet (10BASE-T / 100BASE-TX / 1000BASE-T), USB 1.1, USB 2.0, USB Host |
